پمپ پرتابل هیدرولیک تولید فشار مدل PGS700

موجودی: در انبار
کد محصول: PGS700
وزن: 1.30kg

0 تومان

پمپ پرتابل هیدرولیک تولید فشار مدل PGS700-N14با رنج تولید فشار هیدرولیک range 0 to700 bar با خروجی 1/4 NPT ساخت Eurotron انگلستان

The PGS-700 hydraulic pressure test pump provide hydraulic pressure up to 700 bar (10000 psi). It operates both with OIL or WATER

Range 0 to 700 bar
Oil or Water operated
High Pressure/Priming Selection
Precise fine adjustment valve and controlled Vent
Supplied with test hose
Unique Priming/high pressure selector mode for quick operation
Large transparent 200 CC reservoir
Controlled pressure release and fine adjustment
High Pressure Flexible Test Hose as standard
Compatible with mineral Oil or Water
Supplied as pump only or in KIT version
Wide choice of digital and analogue test gauges

مشخصات فنی

مشخصات فنی

General
Pressure Range	0 to 700 bar/10000 psi
Medium	Mineral oil based hydraulic fluid or distilled water, like used for flat irons (e.g. from local super market
Fluid Reservoir	Volume > 200 cm³, can be filled during stroking
Test hose	1 mt high pressure flexible hose, detachable ( other length available on request)
Dimension	approx. 270 x 160 x 120 mm (without test hose)
Weight	approx. 1.3 kg (without test hose)
Material	Aluminium, brass, ABS, Plexiglas, NBR
Process Connections : Model PGS700
Reference Port	G1/2 swivel adapter
Test point	Test hose with G1/4 swivel adapter
Process Connections: Model PGS700-N14
Reference Port	1/4″ NPT (F) adapter
Test point	Test hose with 1/4″ NPT (F) adapter
