قلع کش دستی برقی مول FR-301

قلع کش دستی برقی مول FR-301
قلع کش دستی برقی مول FR-301
قلع کش دستی برقی مول FR-301
قلع کش دستی برقی مول FR-301
قلع کش دستی برقی مول FR-301
قلع کش دستی برقی مول FR-301
قلع کش دستی برقی مول FR-301
  • موجودی: در انبار
  • تولیدکننده: HAKKO
  • کد محصول: FR-301
  • وزن: 0.70kg
0 تومان

قلع کش دستی برقی مول FR-301 با رنج قابل تنظیم دمایی 350-500 درجه سانتیگراد بهمراه متعلقات استاندارد و کیف حمل ساخت Hakko ژاپن



A wide range of nozzles and shapes for any desoldering

Use of high thermal efficiency N61 series nozzles

N61 series nozzles can also be used for FR-410 desoldering station.
* N61 series nozzles cannot be used for FR-300.

A wide range of nozzles and shapes for secure desoldering

The nozzles lineup includes diameters from 0.6 mm to 1.6 mm and also oval shape nozzles. Desoldering on micro land and in fine pitch can be possible.

N61 series nozzles for FR-301

Equipped with high-precision temperature control function

Uses HAKKO’s unique sensor feedback control method.

Easy temperature control

  • CAL enables fine adjustment of temperature
  • LED indicators let you easily see when the heater is active and idling at your temperature setting.

Reduction of solder clogging by improved heating core

  • In comparison with the previous model

Easy filter maintenace

The structure of the filter pipe is same as FR-410 desoldering station. That makes it easier to clean the filter pipe compared to the previous model.

The filter pipe assembly, a set of the five parts, is also available.

Part numbers of the replacement parts

Quick Change Nozzle System provides speed and safety

The Quick Change Nozzle System allows for a safer and simpler method to quickly remove nozzles for cleaning or replacement, even when the unit is hot.

Includes simple iron holder

Prevents burns and accidents with hot parts

Power switch on grip

Convenient for temporal stop of operation. Turning off the power can reduce nozzle oxidation.

Includes carrying case

Comes with a carrying case for prompt storage after use.

مشخصات فنی
مشخصات فنی

Specifications

Model No.FR-301
Power consumption100 V 98 W (50/60 Hz)
110 V 122 W (50/60 Hz)
120 V 140 W (50/60 Hz)
220 V 100 W (50/60 Hz)
230 V 110 W (50/60 Hz)
240 V 120 W (50/60 Hz)
Temperature range350 to 500℃
Nozzle to ground resistance<2 Ω
Nozzle to ground potential<2 mV
Vacuum generatorDiaphragm pump
Vacuum pressure81 kPa (610 mmHg)
Suction flow11 L/min.
Heating elementCeramic heater
Standard nozzle1.0 mm dia. (No. N61-08)
Dimensions215 (W) × 226 (H) mm (with N61-08 nozzle)
Weight0.52 kg (with N61-08 nozzle)



  • Total length and weight are measured without cord.
